Spring Boot 4.1's SSRF Mitigation Is Opt-In: How to Actually Close the Hole
Spring Boot 4.1's InetAddressFilter only protects you once you declare it, and it never sees HttpClient or OkHttpClient beans you build yourself. How I lock down outbound HTTP, and mutual-TLS the internal gRPC calls, in a payments microservice stack.
Open the webhook sender in almost any payments service and you will find a method that reads a URL out of a database row and calls it. A merchant registered the address during onboarding. A partner bank supplied a callback host. A KYC vendor returned a link to a scanned document. The call is a single line, restClient.get().uri(url).retrieve(), and it is also the line where an attacker can make your service fetch http://169.254.169.254/latest/meta-data/iam/security-credentials/ for them.
Spring Boot 4.1 ships a first-party defence for this. I went through the 4.1.0 RC1 release notes and then looked at how the feature behaves in a service with hand-built HTTP clients. Two things are easy to miss. The filter does nothing until a bean exists for it, and it only covers the clients Boot itself builds.
Below I cover both gaps, show a resolver-level guard for clients Boot cannot see, and write the tests that show the hole is shut. I also treat the code filter as the last of several layers, since egress control belongs underneath it. Then I turn to the other 4.1 change that matters for microservice teams: gRPC server and client auto-configuration now lives inside Boot, which makes mutual TLS between internal services a configuration exercise.
Why payment backends get hit
A service in a private network can reach what the public internet cannot: the cloud instance metadata endpoint, the Kubernetes API server, an admin port bound to the pod network, a Redis instance left without a password because only cluster traffic reaches it. If an attacker controls where one outbound request goes, the service's network position becomes theirs.
Payment systems have more of these attacker-influenced destinations than most. In the services I have worked on, they come from four places:
- Webhook targets that merchants type into a dashboard.
- Callback and token endpoints belonging to partner banks and processors, stored in configuration or onboarding records.
- Document links (statements, logos, KYC scans) submitted through forms.
Locationheaders on responses from third parties, if the client follows them.
On a node where the metadata service still accepts unauthenticated GETs, the first request to 169.254.169.254 can return temporary cloud credentials, and everything after that depends on how broad the instance role is.
My time on the OpenBanking PSD2 side of fintech shaped how I read partner-supplied hosts. The whole model there is calling other organisations' endpoints, and a hostname being on the partner's onboarding sheet says who signed a contract. It says nothing about where the name resolves today. Partner infrastructure gets compromised, lapsed domains get registered by someone new, and a name that pointed at a public address last month can be repointed at 10.0.4.17 by whoever controls its DNS zone.
What 4.1 gives you
The new type is InetAddressFilter. It is evaluated after DNS resolution, against the InetAddress the client is about to connect to. That placement is the reason it works better than URL inspection. A string check for 169.254 in the host loses to a decimal-encoded IP, an IPv4-mapped IPv6 literal, a trailing dot, or simply a domain the attacker owns whose A record is the metadata address. Looking at the address that will actually receive the SYN makes the spelling of the URL irrelevant.
InetAddressFilter.externalAddresses() is the built-in factory. As I read the release notes, it refuses loopback, private-range, multicast and other special-purpose addresses, including the link-local block that holds the metadata endpoint. Check the exact set against the Javadoc for your patch version rather than relying on my summary. Once a filter bean exists, Boot attaches it to the clients it auto-configures: RestClient, RestTemplate and WebClient.
The opt-in is one bean:
@Configuration(proxyBeanMethods = false)
class OutboundSecurityConfig {
// No bean, no filtering. Boot 4.1 does not install this on its own.
@Bean
InetAddressFilter outboundAddressFilter() {
return InetAddressFilter.externalAddresses();
}
}
Most write-ups on the feature stop at this snippet. The next two sections are about what it leaves open.
Gap one: no bean, no protection
Take a project on 4.1 with no InetAddressFilter bean and point a test at a WireMock instance on 127.0.0.1. My prediction, which follows directly from the opt-in design and which you can confirm in five minutes, is that the call succeeds. Nothing is installed, so nothing blocks.
Here is the version of this that worries me. A platform team sees "Spring Boot 4.1 mitigates SSRF" in the release notes, raises the parent POM version across its services, and closes the ticket. I am describing a scenario, not a specific company. The upgrade changed no behaviour for SSRF. Every service is as exposed as before, and the tracker says otherwise.
What I do about it is put the bean in a shared internal starter and add a startup check beside it. If a service has a RestClient.Builder bean but no InetAddressFilter, it refuses to boot outside local and test profiles:
@Component
@Profile("!local & !test")
class OutboundFilterGuard implements SmartInitializingSingleton {
private final ObjectProvider<InetAddressFilter> filter;
OutboundFilterGuard(ObjectProvider<InetAddressFilter> filter) {
this.filter = filter;
}
@Override
public void afterSingletonsInstantiated() {
if (filter.getIfAvailable() == null) {
throw new IllegalStateException(
"No InetAddressFilter bean declared, so outbound SSRF protection is OFF. "
+ "Import OutboundSecurityConfig, or record an explicit exception for this service.");
}
}
}
The !local & !test profile expression is a trade-off. Local runs and integration tests talk to WireMock, Testcontainers and embedded servers, all of which live on loopback, and an enforcing filter would break them. The cost is that the guard never runs in those profiles, so the tests described later in this post, which exercise the real resolver explicitly, are what keep the protection covered in CI. If you want the filter active in test profiles too, you will need an allow exception for loopback that exists only there, and that exception must never ship in a production profile.
Gap two: clients you build yourself
Boot's filter reaches clients through its own auto-configuration. Define your own HttpClient, CloseableHttpClient or OkHttpClient bean and wrap it in a request factory, and Boot's customisation never touches it. As far as I can tell nothing logs a warning either, so you find out by testing, not by reading startup output. If you have verified different behaviour on a specific 4.1.x build, put your finding next to mine: I haven't tested every client type.
Real payment code ends up here constantly, because partner integrations ask for things the defaults can't do:
- Mutual TLS with a keystore dedicated to one partner.
- A pool sized to a processor's cap on concurrent connections.
- Timeouts that differ per acquirer, so a slow one cannot starve the others.
- An OkHttp interceptor that produces the detached JWS signature a bank requires.
Each requirement leads to a hand-built client, and a hand-built client is outside Boot's reach. The remedy is to attach the address check to the client yourself. For Apache HttpClient 5 the narrowest point is the DnsResolver, because every connection attempt passes through it. This version uses only JDK address classification, so it does not depend on Boot internals, and it takes its delegate as a constructor argument so tests can feed it canned answers:
public final class PublicOnlyDnsResolver implements DnsResolver {
private final DnsResolver delegate;
public PublicOnlyDnsResolver() {
this(SystemDefaultDnsResolver.INSTANCE);
}
PublicOnlyDnsResolver(DnsResolver delegate) {
this.delegate = delegate;
}
@Override
public InetAddress[] resolve(String host) throws UnknownHostException {
InetAddress[] resolved = delegate.resolve(host);
for (InetAddress address : resolved) {
if (isForbidden(address)) {
// Host and address only. The full URL can carry tokens.
throw new BlockedDestinationException(
"Blocked outbound connection: " + host + " resolved to " + address.getHostAddress());
}
}
return resolved;
}
@Override
public String resolveCanonicalHostname(String host) throws UnknownHostException {
return delegate.resolveCanonicalHostname(host);
}
static boolean isForbidden(InetAddress address) {
if (address.isLoopbackAddress() || address.isAnyLocalAddress()
|| address.isLinkLocalAddress() || address.isSiteLocalAddress()
|| address.isMulticastAddress()) {
return true;
}
byte[] raw = address.getAddress();
if (raw.length == 4) {
int first = raw[0] & 0xFF;
int second = raw[1] & 0xFF;
// 100.64.0.0/10 (carrier-grade NAT) and 198.18.0.0/15 (benchmarking)
// are not covered by the JDK helpers above.
return (first == 100 && (second & 0xC0) == 0x40)
|| (first == 198 && (second & 0xFE) == 18);
}
// fc00::/7, IPv6 unique-local
return raw.length == 16 && (raw[0] & 0xFE) == 0xFC;
}
/** UnknownHostException subtype so retry policies can tell policy from network failure. */
public static final class BlockedDestinationException extends UnknownHostException {
public BlockedDestinationException(String message) {
super(message);
}
}
}
On IPv6: InetAddress hands back an Inet4Address for IPv4-mapped literals such as ::ffff:10.0.0.1, so the checks above see the embedded IPv4 value. Other transition formats (NAT64 prefixes, 6to4) are not normalised that way, which is one more reason to run this behind an egress policy that does not care how an address is spelled.
Wire it into a pooled connection manager and give the client to a request factory:
@Bean
RestClient acquirerRestClient(PartnerTlsProperties tls) {
var connectionManager = PoolingHttpClientConnectionManagerBuilder.create()
.setDnsResolver(new PublicOnlyDnsResolver())
.setSSLSocketFactory(tls.mutualTlsSocketFactory())
.setMaxConnPerRoute(20)
.build();
CloseableHttpClient httpClient = HttpClients.custom()
.setConnectionManager(connectionManager)
.disableRedirectHandling() // a redirect is a new destination chosen by someone else
.build();
return RestClient.builder()
.baseUrl(tls.acquirerBaseUrl())
.requestFactory(new HttpComponentsClientHttpRequestFactory(httpClient))
.build();
}
Redirects
I disable automatic redirect handling on any client whose target a tenant or partner can influence. A host you are entitled to call can reply 302 Location: http://169.254.169.254/.... With the resolver installed, the redirected hop goes through the same pooled manager and gets checked, so the guard would likely catch it. Even so, I would rather a human-written branch decide whether a redirect is acceptable than let the client follow one silently. Payment APIs seldom need redirects (a 3-D Secure challenge URL is sent to the browser, not followed by your server). In the few cases that do, write explicit code that validates the new target against the same rules and caps the hop count.
The resolver and DNS rebinding
Checking at resolve time, inside the same call that returns the addresses the connection manager then uses, avoids the classic time-of-check/time-of-use trap where a validator resolves a name once and the client resolves it again and gets a different answer. That holds only because the check and the connect use the same resolver result. If you add a separate pre-flight "is this URL safe" step that does its own lookup, you have reintroduced the race.
For OkHttp the equivalent hook is OkHttpClient.Builder.dns(Dns), and isForbidden can be reused unchanged. I keep that method in one shared library class so a fix to a range lands in every client together.
Allowlists, and the first support ticket
An address filter is a denylist by category. Where destinations form a closed set, use an allowlist instead: the hosts of your partner banks are known, so store them, compare against them, and treat everything else as an onboarding exception needing review. Hold the address filter for the open-ended cases such as merchant webhooks.
Expect friction once merchants hit it. The first ticket is predictable: a merchant has a legitimate endpoint on a private address, perhaps a VPN-fronted ERP or a staging box on an internal range, and every delivery to it is now blocked. Decide the policy in advance. Mine is that there is no per-tenant bypass in the shared library. A merchant that needs private connectivity gets a dedicated delivery path, with its own network route and its own review, and not a flag in the filter.
Proving it with tests
Security code I haven't watched reject something is code I do not trust. Three tests cover the guard. The first two need no network; they check classification and resolution using canned answers:
class PublicOnlyDnsResolverTest {
private static DnsResolver resolvingTo(String... literals) {
return new DnsResolver() {
@Override
public InetAddress[] resolve(String host) throws UnknownHostException {
InetAddress[] out = new InetAddress[literals.length];
for (int i = 0; i < literals.length; i++) {
out[i] = InetAddress.getByName(literals[i]);
}
return out;
}
@Override
public String resolveCanonicalHostname(String host) {
return host;
}
};
}
@ParameterizedTest
@ValueSource(strings = {
"169.254.169.254", // cloud metadata
"127.0.0.1",
"10.0.4.17", // a "public-looking" name pointing at a private range
"172.16.8.9",
"192.168.1.20",
"100.64.3.4", // carrier-grade NAT
"::1",
"fd00::1", // IPv6 unique-local
"::ffff:10.0.0.1" // IPv4-mapped IPv6
})
void rejectsInternalAddressesNoMatterWhatTheNameLooksLike(String literal) {
var resolver = new PublicOnlyDnsResolver(resolvingTo(literal));
assertThatThrownBy(() -> resolver.resolve("partner.example.com"))
.isInstanceOf(PublicOnlyDnsResolver.BlockedDestinationException.class)
.hasMessageContaining("Blocked outbound connection");
}
@Test
void rejectsWhenOnlyOneOfSeveralRecordsIsInternal() {
// Round-robin DNS can mix addresses; one bad record must poison the lookup.
var resolver = new PublicOnlyDnsResolver(resolvingTo("93.184.216.34", "10.0.0.8"));
assertThatThrownBy(() -> resolver.resolve("mixed.example.com"))
.isInstanceOf(PublicOnlyDnsResolver.BlockedDestinationException.class);
}
@Test
void allowsOrdinaryPublicAddresses() throws Exception {
var resolver = new PublicOnlyDnsResolver(resolvingTo("93.184.216.34"));
assertThat(resolver.resolve("partner.example.com")).hasSize(1);
}
}
The third goes through the real client bean, so it exercises the wiring and not only the helper. It relies on a wildcard DNS service resolving to loopback, which means it needs outbound DNS from your CI runners; if yours do not have that, replace the hostname with one your internal test resolver maps to 127.0.0.1:
@Test
void clientBeanRefusesNameThatResolvesToLoopback() throws Exception {
try (var server = new MockWebServer()) {
server.enqueue(new MockResponse().setBody("secrets"));
server.start(InetAddress.getLoopbackAddress(), 0);
// localtest.me resolves to 127.0.0.1: the name looks external, the address is not.
String url = "http://localtest.me:" + server.getPort() + "/latest/meta-data/";
assertThatThrownBy(() -> acquirerRestClient.get().uri(url).retrieve().body(String.class))
.hasRootCauseInstanceOf(PublicOnlyDnsResolver.BlockedDestinationException.class);
assertThat(server.getRequestCount()).isZero();
}
}
The last assertion carries the weight. A request count of zero on the listener shows that the connection was refused before any bytes left the process, which is a stronger statement than "an exception was thrown". Write one test like this per client bean you own. If the codebase has eleven client beans and the test class has six cases, the five missing ones are your list of unprotected paths.
I have not pasted run output here because the numbers would depend on your build and Boot patch release. Run these against your own services and attach the result to the change that introduces the guard; that is the artefact a reviewer or auditor will ask for.
Defence in depth: the code filter is the last layer
Everything above lives in the application. The application is also the layer that gets forgotten, misconfigured and bypassed, so treat it as the final wall and not the only one:
- Egress at the network layer. A Kubernetes
NetworkPolicy, security group or egress firewall that denies the link-local range and RFC 1918 space for pods that only need to reach the internet is the real fix. If application code fails, the packet still goes nowhere. For services that must call arbitrary tenant URLs, route them through an egress proxy or a small webhook-dispatcher service in an isolated network segment, so only that one component holds the risk. - IMDSv2 with a hop limit of 1 on AWS. Version 2 of the metadata service wants a session token obtained with a PUT, which the usual blind-GET SSRF primitive cannot produce, and a hop limit of one keeps container-originated traffic from reaching it. For the metadata attack in particular, this is the highest-value infrastructure change I know of.
- Allowlists wherever the destination set is closed, as described above.
- Short timeouts and response caps. SSRF probing often relies on timing differences to map a network. A two-second connect timeout and a one-megabyte body limit remove most of that signal.
- Egress observability. Tag outbound spans with the resolved address if you already trace requests. I wrote about wiring that up in distributed tracing with OpenTelemetry on Spring Boot. A counter of blocked connections per tenant is a cheap detector, and a tenant whose count suddenly climbs deserves a look.
The other half: gRPC between your own services
Closing the outbound door covers traffic leaving your estate. Traffic between your own services needs the same attention, and Boot 4.1 changes the setup cost here too. The Spring gRPC project (version 1.1.0 at the time of writing) has been brought into Boot, so server and channel configuration arrive through ordinary auto-configuration and properties and not through a separately versioned starter.
For a ledger, risk and settlement split, gRPC gives typed contracts and low overhead. It also gives you one obvious place to enforce transport security, which plain HTTP between pods rarely gets in practice. I count plaintext inside the cluster as a finding.
A ledger service exposing an endpoint looks like this:
@Service
class LedgerGrpcService extends LedgerServiceGrpc.LedgerServiceImplBase {
private final PostingEngine postingEngine;
LedgerGrpcService(PostingEngine postingEngine) {
this.postingEngine = postingEngine;
}
@Override
public void postEntry(PostEntryRequest request, StreamObserver<PostEntryReply> reply) {
// The idempotency key travels in the message body, not in transport metadata,
// so a retry from any hop deduplicates against the same value.
PostingResult result = postingEngine.post(request.getIdempotencyKey(),
request.getDebitAccount(), request.getCreditAccount(), request.getAmountMinor());
reply.onNext(PostEntryReply.newBuilder().setPostingId(result.id()).build());
reply.onCompleted();
}
}
With auto-configuration, that BindableService bean is discovered and registered without hand-assembling a ServerBuilder. Transport security then becomes configuration. The property names below follow the Spring gRPC reference as I understand it, so confirm them against the 4.1.x documentation for your exact patch version before copying:
spring:
ssl:
bundle:
pem:
ledger-server:
keystore:
certificate: file:/etc/tls/ledger/tls.crt
private-key: file:/etc/tls/ledger/tls.key
truststore:
certificate: file:/etc/tls/ca/internal-ca.crt
grpc:
server:
port: 9090
ssl:
bundle: ledger-server
client-auth: need # mutual TLS: a caller without a certificate never reaches your code
client-auth: need is the line that matters. A caller without a certificate chained to your internal CA fails during the handshake, before any of your code executes. With cert-manager issuing short-lived workload certificates, the day-to-day cost is small.
The calling side reuses the SSL bundle mechanism, and the channel factory resolves named channels from configuration:
@Configuration(proxyBeanMethods = false)
class LedgerClientConfig {
@Bean
LedgerServiceGrpc.LedgerServiceBlockingStub ledgerStub(GrpcChannelFactory channels) {
// "ledger" maps to spring.grpc.client.channels.ledger.* in application.yml,
// including its SSL bundle and target address.
ManagedChannel channel = channels.createChannel("ledger");
return LedgerServiceGrpc.newBlockingStub(channel)
.withDeadlineAfter(800, TimeUnit.MILLISECONDS);
}
}
The two halves cover different trust boundaries. Channels to ledger.payments.svc.cluster.local are internal and authenticated by mutual TLS. The InetAddressFilter and the custom DnsResolver belong to the HTTP clients that reach out to the world. Keep them visibly apart in configuration. One line is worth adding to the code review checklist: channel targets come from configuration, never from request data. If anyone writes ManagedChannelBuilder.forTarget(valueFromARequest), they have rebuilt the SSRF hole one protocol over, and the HTTP-layer controls will not see it because gRPC does not travel through those clients.
Behaviour under failure
A hardened path still has to fail sensibly. Two changes are worth making before the first load test, not after:
- Blocked calls must not retry. Many resilience configurations treat
UnknownHostExceptionas transient and retry it with backoff. A blocked address is a policy decision, so retrying it three times only triples the log volume and delays the alert. That is whyBlockedDestinationExceptionis its own subtype above: exclude it from the retry predicate. - Webhook delivery needs a terminal state for rejected destinations. When the filter rejects a merchant's endpoint, the event cannot silently disappear. Park it and flag the merchant record for review. If you deliver through an outbox, as in the transactional outbox and idempotent consumers post, a blocked destination becomes a terminal status on the outbox row and not an endless retry loop.
Also plan for false positives from things that legitimately call loopback or private addresses: health checks, sidecar proxies, Actuator scrapes and calls to a local agent. Those should not use the clients you are guarding. If they do, keep them on a separate client bean with a narrow, documented purpose and no tenant-controlled input.
Order of work for an existing estate
If I were given a fintech microservice estate on 4.1 and a quarter to make it safer, this is the order I would go in:
- Ship the shared starter that declares
InetAddressFilter.externalAddresses(), along with the startup guard that fails a deploy when the bean is missing. - Search for
HttpClient,CloseableHttpClient,OkHttpClientand Feign builders. Every hit is a client the Boot filter cannot see. Give each the resolution-time guard and a test like the ones above. - Turn off automatic redirects on anything that calls a tenant-controlled URL.
- Enforce IMDSv2 with hop limit one on every node, and add egress policy that blocks the link-local and private ranges for workloads that have no reason to reach them.
- Move internal gRPC to mutual TLS through SSL bundles, and ban request-derived channel targets in review.
None of this is exotic. It removes a whole class of incident from the risk register, and the framework now gives you a starting point where there used to be a blank file.
If you suspect your outbound clients are less covered than the dashboards claim, my background across airline-scale traffic and fintech platforms is a reasonable place to begin a conversation. Send the list of HTTP client beans in your busiest service through the contact section, and I will tell you which of them the Boot filter never touches.
Related Articles
- OpenBanking PSD2 API Development: the partner-integration side of fintech, where every outbound call needs a threat model.
- Distributed Tracing with OpenTelemetry on Spring Boot in Production: how to make blocked and suspicious egress visible.
- Transactional Outbox and Idempotent Consumers for Spring Boot Payment Systems: reliable webhook delivery, including what to do when a destination is rejected.
